250 kg
9.0 m - 22.2 m
0.7 m × 1.5 m × 0.95 m
30.4 m
| Max. Bucket Capacity | 250 kg | |
|---|---|---|
| Bucket Material | Steel | |
| Max. Bucket Floor Height | 30.4 m | |
| Max. Bucket Floor Depth | 7.5 m | |
| Bucket Swing Angle | 313° (Left 93° – Right 220°) | |
| Internal Bucket Dimensions | 0.7 m × 1.5 m × 0.95 m | |
| Boom Length | Min. Retracted | 9.0 m + 5.2 m |
| Max. Extended | 22.2 m + 7.6 m | |
| Elevation Angle | -12° – 80° | |
| Boom Type | Telescopic & Knuckle | |
| Extend Width | Max. | 4.4 m |
